Air Double Diaphragm Pump 7GPM 100PSI Polypropylene Diaphragm Water Pump With 1.3 Cm Inlet & Outlet Ports Air Pump Diaphragm 6900.7 Cm Max Head Air-operated Diaphragm Pump With Sealed Ball Valve

Core functional modules Durable materials and sturdy structure Shell material: Made of polypropylene material, fully bolted structure, sturdy and corrosion-resistant. Diaphragm configuration: double PTFE diaphragm design, strong corrosion resistance and aging resistance. Protection parameters: Maximum temperature tolerance of 150 ℉ (66 ℃), maximum pressure of 100 psi, suitable for harsh working conditions. Efficient and stable conveying performance Flow rate and head: The maximum flow rate is 8.8 GPM, the maximum head is 69m (226.4ft), the suction range is 0-5m (0-16.4ft), and the conveying efficiency is high. Suitable media: Can handle fluids containing up to 2.38mm (3/32 inches) suspended solids, compatible with viscous and flammable media (such as waste oil, alcohol, gasoline, diesel, detergents, drinking water, etc.). Pneumatic advantages: The motor design ensures air efficiency, the "unbalanced" air valve avoids operation jamming, and the performance is stable and reliable. Professional structural design Interface specifications: Import and export size 1/2 inch (12.7mm), air inlet size 1/4 inch (6.35mm), air nozzle size 0.32 inch (8mm), in compliance with industry standards. External air distribution system: equipped with an external maintainable air distribution system that meets international standard performance requirements. Sealed ball valve: Adopting a sealed ball valve design to enhance the sealing and stability of transportation.
